#EHD117 Aerodynamics Wind Tunnel for Modern Aircraft System.

Aerodynamics Wind Tunnel for Modern Aircraft System.

Project Fee:Negotiable

Project Discount:0

Project Duration:One Month

Aerodynamics Wind Tunnel for Modern Aircraft System.

1. Introduction

The Aerodynamics Wind Tunnel for Modern Aircraft System is designed to study airflow around aircraft models and understand their aerodynamic performance. The system uses a controlled airflow chamber, a fan, and measurement sensors to observe how air velocity and aerodynamic forces affect an aircraft's shape. It provides an educational platform for exploring lift, drag, and airflow behavior in modern aircraft design.

2. Objectives

  • Study airflow around aircraft models.

  • Understand lift and drag forces.

  • Measure airflow velocity and pressure.

  • Analyze the effects of aircraft shape on aerodynamics.

  • Compare aerodynamic performance under different conditions.

  • Support aircraft design and engineering experiments.

3. Methodology

  • Construct a wind tunnel with an airflow chamber.

  • Install a fan to generate controlled airflow.

  • Place a miniature aircraft model inside the test section.

  • Use sensors to measure air velocity and pressure.

  • Measure aerodynamic forces using a force sensor setup.

  • Compare experimental readings at different airflow speeds and model angles.

4. Instrument List

  • DC Fan or Blower

  • Wind Tunnel Test Chamber

  • Aircraft Model

  • Arduino Uno

  • Anemometer

  • Pressure Sensor

  • Load Cell

  • Motor Speed Controller

  • LCD Display

  • Battery

5. Working Principle

  • The fan generates airflow through the wind tunnel.

  • The airflow passes through the test section containing the aircraft model.

  • The shape and angle of the model influence airflow distribution and aerodynamic forces.

  • The anemometer measures air velocity, while pressure sensors record pressure changes.

  • The load cell measures forces acting on the model.

  • The controller displays the collected data for analysis of aerodynamic performance.

6. Advantages

  • Controlled airflow testing

  • Improved aerodynamic understanding

  • Measurement of lift and drag

  • Aircraft model performance analysis

  • Repeatable laboratory experiments

  • Support for aircraft design education

7. Conclusion

The Aerodynamics Wind Tunnel for Modern Aircraft System provides a practical way to study airflow and aerodynamic forces using scaled aircraft models. By combining controlled airflow with sensors and data monitoring, the project helps demonstrate the principles of lift, drag, and pressure distribution. The accuracy of the results depends on wind tunnel design, sensor calibration, and the scale of the model
