This project helps to control the electrical loads with the help of android application. The electrical loads are controlled based on Bluetooth input signal.
Project Fee:Negotiable
Project Discount:0
Project Duration:One Month
About This Project:
In This project is to make an android
controlled Home Automation. It will help in building an android controlled Home
appliances without any experience in android app development by providing the
free android app. This app consists of touch controlling interface of Home appliances.
This Project includes two distinct parts, hardware control circuit and the
android application. The communication between the Control circuit and the
android application is carried over by the Bluetooth link between the phone’s
Bluetooth and the Bluetooth device in the control circuit. The ASCII commands
are sent from the phone to the Robot which in turn checked by the Arduino for
the turning ON or OFF of the particular device. This project helps to control
the electrical loads with the help of android application. The electrical loads
are controlled based on Bluetooth input signal. This input signal is received
from the android device. Many times it becomes too tiring to operate the
electrical switches manually every now and then. This is a big problem
especially in case of aged or handicapped people. This system solves the issue
by interfacing a unit with home appliances that switches these loads based on
the input received from android device. The android device may be any android
based phone or tab having an android OS. The app also provides an effective GUI
for providing this functionality. An Arduino is used in this system. The
Bluetooth receiver is interfaced with microcontroller in order to accept the
commands and then react accordingly. It operates the loads through a set of
relays using a relay module. Relays are used between loads and the control unit.
This system proves to be very beneficial for controlling various domestic
applications and in industrial setups. The power supply setup of the system
contains a step down transformer of 230/12V, used to step down the voltage to
12VAC. To convert it to DC, a bridge rectifier is used. In order to remove the
ripples, a capacitive filter is used and it makes use of 7805 voltage regulator
to regulate it to +5V that will be needed for microcontroller and other
components operation.
Block Diagram:
Required Instrument:
-
Arduino.
-
Bluetooth Module HC-05.
-
Relay.
-
Transistor.
-
Voltage Regulator IC7805.
-
Transformer.
-
Diode.
-
Capacitor.
-
Voltage Regulator.
Advantages:
-
Provides safety
from electrical power short circuits while using conventional wall switches to
operate loads.
-
Home automation
system Provides many facilitates & more security.
-
Save a lot of
time to operate from remotely without wasting time.
-
Fan, Door Lock,
Light, & Switch can be operated.
-
Prevents wastage
of energy.
-
No need to carry
separate remote or any other controlling unit.
Applications:
- Home Automation – This project can be used to control various Home Appliances.
Buy All Electronics Components:
Any modification of this project can be done as per your requirement. We will make the project according to your needs. Contact us with your any innovative engineering projects idea. We will help you to implement your project.
